Wizard Cooling Radiator, LS Swap - 88-98 GM Truck / 92-99 SUV - Supercharged

- Only fits trucks with 40" wide radiator / mounts (also labeled as 34" core)

Must have flat upper radiator mounts, NOT raised for tall radiator (See image)

• Engine: LS Swap (Supercharged)
• CRITICAL THICKNESS: 6.50 IN
• THICKNESS OF CORE: 2.75 in (Upgraded High Performance Core)
• TRANSMISSION OIL COOLER INCLUDED: Yes
• Core Thickness: 2.75 in (Upgraded High Performance Core)
• Electric Fan Type: Brushless
• INLET LOCATION: Driver Side
• OUTLET LOCATION: Passenger Side
• OUTLET HEADER WIDTH: 3 IN
• CORE MATERIAL: Aluminum
• TUBE INSIDE DIAMETER: 1.25 IN
• TRANSMISSION OIL COOLER TYPE: Plate
• CORE ROW QUANTITY: 2
• TOTAL CFM (ALL FANS): 6600
• CORE WIDTH: 34 IN
• TANK MATERIAL: Aluminum
• CUBIC INCHES OF CORE: 1730 CuIn
• DOWN FLOW OR CROSS FLOW TYPE: Cross Flow
• ENGINE OIL COOLER FITTING GENDER: Female
• OUTLET HEADER LENGTH: 18.75 In
• OUTLET DIAMETER: 1.625 IN
• NUMBER OF ELECTRIC FANS: 2
• MOUNTING TYPE: Saddle
• INLET HEADER WIDTH: 3 IN
• INLET HEADER LENGTH: 18.75 In
• INLET DIAMETER: 1.375 IN
• ENGINE OIL COOLER INCLUDED: No
• CORE HEIGHT: 18.75 IN
• FINISH: Aluminum
• SHROUD TYPE: Shroud
• PACKAGE: Radiator & Fan Package
