React Inline Trans Cooler Bracket - 63-87 C10

This universal transmission cooler bracket can be mounted in multiple locations on a C10. It has been designed to be used with a Derale 13740 transmission cooler. When used with the Derale 13740, the bracket does not have to be located in direct air-flow to properly cool; the electric fans will provide enough airflow.

14.125" Wide (Frame Mounted Side)
10.25" Deep (How Far it Sticks Out From the Frame)
4.125" Tall (5.00" Tall w/ Cooler Installed)

TRANSMISSION COOLER NOT INCLUDED, ADD ABOVE
WE RECOMMEND USING IN CONJUNCTION WITH COOLER IN RADIATOR

Features:
3/16" Plate Steel
Flexible Installation
Drilled to be Mounted with Derale 13740 Cooler

Includes:
Mounting Hardware
