DD-2575-4

Dirty Dingo LS Conversion Mount 4WD - 88-98 GM Truck / 92-99 SUV

Dingo Truck Mounts are precision CNC laser cut from .250 thick 1050 High Carbon cold rolled steel. LS adjustable conversion mounts are for installing the 1997-2013 Gen III/IV LS series engine into older Chevrolet/GM trucks. They are slotted for adjustment with engine placement in the engine compartment. These mounts will allow you to move the engine from the original bell housing position up to 2 1/2 inches forward, and up to 1/2 inch rearward. When torqued in place they do not allow the engine to move, even under high horsepower applications. Precision CNC press brake folded with large radius die to reduce stress on the bends. These conversion mounts are designed to be used with the factory rubber clam shell style mounts on your original frame. These mounts allows the installation of TH350, TH400, TH700R4, 4L60E, 4L65E, 4L80, and any other combination of standard or automatic transmissions. Grade-8 zinc coated hardware including new cross bolt.

* (Raw steel not painted) Black texture powder coat is available. Make your selection below.

* Sold in pairs, left and right. "D" is the Drivers side, "P" is the Passenger side. Arrows point forward.

* These mounts will clear low mount alternators but the amount of adjustment may be limited.

* Clears LS truck oil pan with a small notch on the driver side of the crossmember.

Customer Reviews

Based on 1 review
0%
(0)
0%
(0)
0%
(0)
100%
(1)
0%
(0)
D
Damien Whittington
Didn’t get the part I ordered

Quality looks great but I ordered for a 94 Chevy 1500 4X4 and got 73-87 2wd mounts. Nobody tried to make it right, just told me they should work. What’s the point of separate part # if they are supposedly universal

Thanks for the review. The part inside the box fits multiple applications and is the exact same, only difference being the label on the outside. That reason is to help 'track' sales numbers. If you returned that mount, it would literally be put in another box with a sticker saying 88-98 4wd mount. You even called the manufacturer who confirmed this as well, so not sure why the issue. We told you it is the same part, different sticker on the box, and the manufacturer did.
You can send it back, I can re-box, and return it right back to you with a new sticker. Its all the same.
